MH36
MH36
The MH36 is the most compact material handler in our product range, designed for operations where agility, speed and efficiency are essential. Despite its smaller size, the MH36 delivers impressive performance in light-to-medium duty handling tasks.
Built on a solid Caterpillar excavator base, the MH36 is equipped with our own boom & stick, cabin and undercarriage to create a highly capable and reliable material handler. Its compact design makes it ideal for sites with limited space, while still offering the lifting performance needed for everyday loading and sorting work.
We offer several options for this machine, each suited to different working conditions and applications.
Weight
The total weight of this machine is 65 tonnes / 105 000 lbs
Engine
The MH36 is equipped with a Caterpillar C9.3B diesel engine (232 kW net power), with 6 cylinders and a 9.3-liter displacement.
The engine meets Stage 5 / Tier 4 Final emission standards.
This machine is available with three power options: diesel, fully electric, or dual-drive (hybrid).
Cabins
– Cab Raiser
– Fixed Cab Raiser
– Movable Cab
Front ends
11 meter / 36 ft
13 meter / 42 ft
16 meter / 52 ft
18 meter / 59
Undercarriages
This machine is available with several different undercarriage options, each designed for specific working conditions. Every undercarriage type offers its own advantages in terms of mobility, stability and lifting performance.
Available undercarriage configurations include:
-
Wheeled Pick & Carry – Highly manoeuvrable and ideal for operations where the machine needs to travel frequently between work areas.
-
Wheeled Pylon – Provides elevated visibility and improved clearance, making it suitable for loading operations where height is essential.
-
Wheeled (LRC only) – A low-profile, stable wheelbase specifically engineered for customers requiring a compact footprint.
-
Crawler Tracks – Available with triple grousers, double grousers or flat shoes for optimal traction and stability on soft, uneven or heavy-duty surfaces.
-
Gantry (MG4300 / MG7500) – Allows trucks and trailers to pass underneath for extremely efficient loading and unloading in port and terminal environments.
Each undercarriage type is engineered for different tasks, enabling the machine to operate efficiently whether it’s working on paved yards, construction sites, bulk terminals or demanding industrial terrain.
